TECHNICAL SPECIFICATIONS
| Engine model | Engine powerkW/rpm | Lift heightmm | Load capacitykg | Load centermm | Model | Travel speed(Unloaded)km/h | Turning radiusmm |
|---|---|---|---|---|---|---|---|
| GM/4.3L | 70 / 2,300 | 2,930 | 5,000 | 600 | 50L-7A | 22.8 | 2,947 |
50L-7A
Engine model
GM/4.3L
Engine powerkW/rpm
70 / 2,300
Lift heightmm
2,930
Load capacitykg
5,000
Load centermm
600
Travel speed(Unloaded)km/h
22.8
Turning radiusmm
2,947
SAFETY
- DUO sensitive ELR(Emergency Locking Retractive) Seat belt
- Seat belt interlock
- TS mast
- Mast Accumulator for load cushioning
- Speed limit setting
- Tilt Lock (Standard)
- Operator Presence Sensing System (OPSS)
- Blue Spot
- Low Leak Valve at Lift Down (Standard)
- Prevention of Sudden Drop when Rupture of Piping (Standard)
- During Engine (Motor) Stop, Steering (HPS: Hydraulic Power Steering) (Standard)
